Whether it is tear resistance, flexibility, abrasion or impact resistance tests, our various techniques and physical situations will reveal what the strengths and weaknesses of clothing, footwear or leather goods accessories that you made.

PHYSICAL AND MECHANICAL RESISTANCE

Among the many tests that CTC laboratories can offer you, here are three examples of physico-mechanical strength analysis to characterize your products.



Impact resistance for women’s shoe heels

Objective

This test is used to reproduce heel impacts associated with walking. In this way we can anticipate the impact resistance of the heel and / or its attachment.

Principle

The test consists of subjecting the heel to impacts on a pendulum impact tester in order to check that the heel or heel attachment resistance is satirfactory.
The result corresponds to the number of impacts taken to break or detach the heel.



test de resistance au choc talon

Impact resistance for women’s shoe heels



Determination of flex resistance

Objective

This test reproduces the stresses to which the materials are subjected during flexing movements, and is used to check the behaviour of the materials, their coating finishes, etc.



Principle

The test consists of repeating a swinging flex motion after mounting a specimen on a special machine commonly known as the Bally flexometer.  The test can be performed dry and/or wet.  The results correspond to the number of flexes taken to obtain deterioration of the material (crack, detachment, split, etc.) in dry or wet conditions.



Determination of flex resistance

Determination of flex resistance



Adhesion strength of bonded assemblies

Objective

This test is used to evaluate the resistance of glued joints between various parts. This test can be performed as-is or after ageing.

Principle

The test consists of taking a sample representative of the joint to be tested, and subjecting it to a constant tensile force in order to measure the separation forces.
The result corresponds to the adhesion strength expressed in daN/cm*.
